HYDRAULIC MOTOR MT 200
Article code:
13329
OEM:
9990000093328
Tax rate
22 %
Price without VAT:
319,67 €
Price with VAT:
390,00 €
Ref:
4
|
Supplier |
Turkey |
|
|
Return or exchange |
14 days |
|
|
Warranty |
6 months |
|
|
cm/rev |
250 |
|
|
Revolutions |
Constant |
495 |
|
[rpm] |
Intermittent operation |
600 |
|
Torque |
Constant |
73 |
|
[Nm] |
max. |
102 |
|
Power [kW] |
Constant |
33,5 |
|
Pressure |
Constant |
200 |
|
[bar] |
Intermittent operation |
240 |
|
max. |
280 |
|
|
Oil flow |
Constant |
125 |
|
[L/min] |
Intermittent operation |
150 |
|
Connection thread |
3/4" |
|
|
Weight [kg] |
22,2 |
|
|
Shaft diameter [mm] |
40 |
|
|
Shaft length [mm] |
80 |
|
L [mm] |
L1 [mm] |
L2 [mm] |
|
|
MT 160 |
190 |
16,5 |
140 |
|
MT 200 |
195 |
21,5 |
145 |
|
MT 250 |
201 |
27,8 |
151 |
|
MT 315 |
211 |
37 |
161 |
|
MT 400 |
221 |
47,5 |
171 |
|
MT 500 |
235 |
61,5 |
185 |
DIAGRAM "MT 250"
supplier:
Spain
max. torque (peak):
83 daNm
max. torque (constant):
58 daNm
axle diameter:
40 mm
cm/rpm:
200
thread:
3/4"
product weight:
21,60 kg
max. flow (constant):
125 l/min
max. flow (with breaks):
150 l/min
max. pressure (peak):
280 bar
max. pressure (constant):
200 bar
max. pressure (with break):
240 bar
max. rpm (constant):
615 rpm
max. rpm (with breaks):
750 rpm
return or exchange:
14 days
length:
shaft - 82mm
warranty:
6 months
output connection:
drainage - 1/4"
max. power (constant):
34kW
